Keysight 33622A WG3-class Trueform Waveform Generator, 2 Number of channels, 120 MHz

Product Detail

Highlights

Generate Trueform arbitrary waveforms with less jitter, more fidelity and greater resolution

Exclusive Trueform technology

• Unmatched capabilities for generating a full range of signals for your most demanding measurements

• Sine waves with 5x lower harmonic distortion for more pure signals

• Pulses up to 100 MHz with < 1 ps jitter for more precise timing

• Trueform arbitrary waveforms with sequencing for more accurate representation of user-defined signals

Instrument features

• 1 GSa/s sampling rate for higher time resolution arbitrary waveforms

• 14-bit resolution with 1 mVpp to 10 Vpp amplitude for greater amplitude accuracy

• 4 MSa/channel standard waveform memory, optional 64 MSa/channel for your longest waveforms

• USB, LAN (LXI-Core), GPIB optional for quick and easy connectivity to PC or network

Waveform creation and editing

• Create a waveform from the front panel using the built-in editor

• Capture a waveform from an oscilloscope and download it to the generator

• Create a waveform in MATLAB or Microsoft Excel and download it to the generator




Keysight 33600A Series waveform generators with exclusive Trueform signal generation technology offer more capability, fidelity, and flexibility than previous generation DDS generators. Easily generate the full range of signals you need with confidence that the signal generator is outputting the signals you expect.


The 33622A can be easily upgraded as your needs change.
