Product Detail
The Keysight DSOX4024G Digital Oscilloscope is a member of the InfiniiVision 4000G X-Series that combines high speed, advanced analysis, and intuitive touch controls.
Equipped with four analog channels, it is ideal for multi-channel measurements, signal synchronization, and analysis of relationships between digital and analog circuit nodes.
The oscilloscope is based on MegaZoom IV ASIC technology, which provides a refresh rate of up to 1,000,000 waveforms/s, which allows you to capture even short-term anomalies.
A large 12.1" TFT touchscreen display with gesture support speeds up navigation and measurement setup.
Like all G-series models, the DSOX4024G has a built-in dual-channel WaveGen 20 MHz oscillator, FRA (Bode Plot) functions, mask and limit tests, DVM and frequency counter.
It supports hardware decoding of I²C, SPI, UART, CAN, LIN, USB PD protocols and is compatible with the BenchVue remote control system.
Features
4 analog channels for multi-signal analysis
200 MHz bandwidth expandable under license
Maximum sample rate 5 GS/s (1/2 channel)
Memory depth up to 4 Mpoints (1/2 channels)
Update rate up to 1,000,000 waveforms/s
12.1" TFT touchscreen with gesture support
Built-in 20 MHz dual-channel WaveGen oscillator
FRA / Bode Plot, mask and boundary tests are standard
DVM and frequency counter (up to 8 bits)
Hardware decoding and triggering via I²C, SPI, UART, CAN, LIN, USB PD
Fully compatible with Keysight BenchVue and Infiniium Offline software
