Product Detail
HIGHLIGHTS
500 MHz bandwidth (upgradable)
4 analog channels
achieve up to 16 bits of vertical resolution with our advanced system architecture
capture a longer signal trace with 20 GSa/s maximum sample rate and 100 Mpts/channel of standard memory
get superior signal integrity with an average system effective number of bits (ENOB) of 8.1 bits at full bandwidth
gain increased usability with the multi-touch supported 15 inch capacitive touch screen and standard solid state drive for fast boot and high reliability
access a wide range of protocol, compliance, and analysis software
What's included:
four N2873A 500-MHz passive probes
probe accessory pouch
Keysight I/O libraries suite
localized power cord, front panel cover
8 GHz BNC calibration cable
keyboard and mouse
user guide and programmer’s guide ship on oscilloscope drive
