| Category | Description | Qty | OEM No. |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | REFLECTOR SCREW | 1 STK | E17066330 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | FILAMENT, BERNAS, E220/E500 | 1 STK | E17036990 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | FILAMENT MOUNTING SCREW, TA | 2 STK | E17037001 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | NEW INNER INSULATOR, PHASE 3, BN | 3 EA | E17168271 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | NUT, INSULATOR, OUTER, PHASE 3, BN | 3 EA | E17168281 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | NUT, INSULATOR, OUTER, PHASE 3 | 3 EA | E17168280 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | TOP, END PLATE | 1 STK | E17063160 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | TOP, END PLATE, SHIELD | 1 EA | E17037064 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | SIDE PLATE | 1 STK | E17036921 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | FRONT PLATE | 1 STK | E17014691 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | BOTTOM, END PLATE, SHIELD | 1 STK | E17037065 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | BOTTOM, END PLATE | 1 STK | E17063170 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | BACK PLATE | 1 STK | E17063191 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | FILAMENT CLAMP INSULATOR | 1 EA | E17037010 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | FILAMENT CLAMP | 2 STK | E17036930 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | SPRING, FILAMENT, R/H | 1 STK | E17121430 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | SPRING, FILAMENT, LH | 1 STK | E17121431 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | CLAMP, FILAMENT, SPRING | 2 STK | E17036950 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | SOURCE-FILAMENT FEEDTHRU | 2 STK | E17014840 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | GAS FEED TUBE, TA DUAL VAP. | 1 EA | E17014832 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | REFLECTOR STRAP, DUAL VAP. | 1 STK | E17121420 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | SUPPORT,CHAMBER,LOWER,DUALVAP | 1 STK | E17063150 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | SHIELD, THERMAL, CRUSIBLE, BERNAS | 1 STK | E17071110 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | SUPPORT,CHAMBER,UPPER,DUAL VAP. | 1 STK | E17063140 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | SOURCE-RETAINING ROD | 4 STK | E17132430 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | COMPRESSION SPRING | 4 EA | E40000001 |
| BERNAS LINER SOURCE ASSY (NO VAPORIZER) | RETAINING RING, E-TYPE | 4 EA | E43000005 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | REFLECTOR SCREW | 1 STK | E17066330 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | FILAMENT, BERNAS, E220/E500 | 1 STK | E17036990 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | FILAMENT MOUNTING SCREW, TA | 2 STK | E17037001 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | NEW INNER INSULATOR, PHASE 3, BN | 3 EA | E17168271 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | NUT, INSULATOR, OUTER, PHASE 3, BN | 3 EA | E17168281 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | NUT, INSULATOR, OUTER, PHASE 3 | 3 EA | E17168280 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | TOP, END PLATE | 1 STK | E17063160 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | TOP, END PLATE, SHIELD | 1 EA | E17037064 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SIDE PLATE | 1 STK | E17036921 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | FRONT PLATE | 1 STK | E17014691 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | BOTTOM, END PLATE, SHIELD | 1 STK | E17037065 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | BOTTOM, END PLATE | 1 STK | E17063170 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | FILAMENT CLAMP INSULATOR | 1 EA | E17037010 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | FILAMENT CLAMP | 2 STK | E17036930 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SPRING, FILAMENT, R/H | 1 STK | E17121430 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SPRING, FILAMENT, LH | 1 STK | E17121431 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | CLAMP, FILAMENT, SPRING | 2 STK | E17036950 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SOURCE-FILAMENT FEEDTHRU | 2 STK | E17014840 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | GAS FEED TUBE, TA DUAL VAP. | 1 EA | E17014832 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | REFLECTOR STRAP, DUAL VAP. | 1 STK | E17121420 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SUPPORT,CHAMBER,LOWER,DUALVAP | 1 STK | E17063150 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SHIELD, THERMAL, CRUSIBLE, BERNAS | 1 STK | E17071110 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SUPPORT,CHAMBER,UPPER,DUAL VAP. | 1 STK | E17063140 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SOURCE-RETAINING ROD | 4 STK | E17132430 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | COMPRESSION SPRING | 4 EA | E40000001 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | RETAINING RING, E-TYPE | 4 EA | E43000005 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | BACK PLATE, VAP. | 1 STK | E17063190 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | SOURCE-CLAMPING ROD | 4 STK | E17143760 |
| BERNAS LINER SOURCE ASSY (W/VAPORIZER) | RETAINING ROD CLAMP BASE | 2 EA | E17143770 |
| BERNAS SOURCE KITS | MINOR SOURCE KIT, E500 | 1 KIT | PLANSEE DESIGN |
| WL LINER OPTIONS | END PLATE, ARC CHAMBER 4-38.764 D | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL END PLATE SHIELD TOP | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL BERNAS ARC CHAMBER SIDE PLATE | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL PLATE, TOP, ARC CHAMBER | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL BOTTOM SHIELD | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL PLATTE 5 | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL10 PLATE (BLANK OFF) | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL10 41.793/000/A POS.1 PLATTE | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL10 41.844/000/B PLATTE 2 | 1 EA | PLANSEE DESIGN |
| WL LINER OPTIONS | WL PLATTE MIT BOLZEN | 1 EA | PLANSEE DESIGN |
| MO LINER OPTIONS | END PLATE,ARC CHAMBER | 1 STK | PLANSEE DESIGN |
| MO LINER OPTIONS | END PLATE SHIELD TOP | 1 STK | PLANSEE DESIGN |
| MO LINER OPTIONS | MO BERNAS ARC CHAMBER SIDE PLATE | 2 STK | PLANSEE DESIGN |
| MO LINER OPTIONS | MO PLATE, TOP, ARC CHAMBER | 1 STK | PLANSEE DESIGN |
| MO LINER OPTIONS | BOTTOM SHIELD | 1 STK | PLANSEE DESIGN |
| MO LINER OPTIONS | ARC CHAMBER BOTTOM END CAP | 1 STK | PLANSEE DESIGN |
| MO LINER OPTIONS | PLATE, BOTTOM, BRANKOFF DUALVAP | 1 STK | PLANSEE DESIGN |
| MO LINER OPTIONS | SHIELD,END PLATE TOP, MOLY | 1 EA | E17141700 |
| MO LINER OPTIONS | SHIELD, END PLATE, BOTTOM, MOLY | 1 EA | PLANSEE DESIGN |
| MO LINER OPTIONS | PLATE BOTTOM ARC CHAMBER | 1 STK | PLANSEE DESIGN |
| MO LINER OPTIONS | SOURCE ARC CHAMBER TOP PLATE | 1 STK | PLANSEE DESIGN |
| OEM EXTRACTION | SUPPRESSION ELECTRODE, INSERT | 1 EA | E17026540 |
| OEM EXTRACTION | MANIPULATOR PLATE | 1 EA | E17026530 |
| OEM EXTRACTION | INNER SHIELD CUP | 4 STK | E17002860 |
| OEM EXTRACTION | CERAMIC STANDOFF | 4 EA | E59000003 |
| OEM EXTRACTION | OUTER SHIELD CUP | 4 EA | E17002870 |
| OEM EXTRACTION | GROUND ELECTRODE | 1 EA | E17026550 |
| OEM EXTRACTION | SOURCE HOUSING APERTURE | 1 EA | E17023041 |
| OEM EXTRACTION | CERAMIC STANDOFF | 4 EA | PLANSEE DESIGN |
| OEM EXTRACTION | SHIELDING CUP SUPP FEEDTHRU | 1 STK | E17001611 |
| OEM EXTRACTION | SHIELD,INSULATING SUPPRESSION | 1 STK | E17183480 |
| OEM EXTRACTION | MANIPULATOR, STANDOFF | 1 STK | E12000230 |
| OEM EXTRACTION | MANIPULATOR MOUNTING SUPPORT | 1 STK | E17001960 |
| 2-STEP REDUCER | SHIELD GRAPHITE 2-STEP REDUCER | 1 STK | E17079910 |
| 2-STEP REDUCER | APERTURE, DUAL 2-STEP REDUCER | 1 EA | E17079880 |
| 2-STEP REDUCER | APERTURE DUAL,2-STEP REDUCER | 1 STK | E17079880 |
| ANALYZER | BEAM-LINE ANALYZER | 1 STK | E17016260 |
| ANALYZER | ANALYZER, EXIT APERTURE | 1 EA | E17033420 |
| ANALYZER | SHORT, UPPER, EXIT SHIELD | 1 STK | E17145720 |
| ANALYZER | SHORT, LOWER, EXIT SHIELD | 1 STK | E17145730 |
| ANALYZER | SHIELD, ANAL, LOWER LONG | 1 EA | E17145710 |
| ANALYZER | UPPER ANALYZER SHIELD | 1 EA | E17145700 |
| ANALYZER | VANE REDUCER | 2 EA | E17154740 |
| ANALYZER | SHIELD GRAPHITE ANALYZER | 1 STK | E17182770 |
| ANALYZER | EXIT APERTURE MOD | 1 STK | PLANSEE DESIGN |
| ANALYZER | ANALYZER SHIELD BLOCK, REV. B | 1 STK | PLANSEE DESIGN |
| ANALYZER | SHIELD, ANALYZER, LONG, LOWER | 1 STK | PLANSEE DESIGN |
| ANALYZER | UPPER ANALYZER SHIELD, MOD | 1 STK | PLANSEE DESIGN |
| ANALYZER | LOWER ANALYZER SHIELD, MOD, REV. | 1 STK | PLANSEE DESIGN |
| ANALYZER | VANE REDUCER, SHORTENED | 2 STK | PLANSEE DESIGN |
| MIRROR | DEFINING APERTURE SUPPORT | 1 STK | E17061280 |
| MIRROR | DEFINING APERTURE | 1 EA | E17026590 |
| MIRROR | 60KV,MIRROR | 1 STK | E17030530 |
| MIRROR | MIRROR INSULATOR | 2 EA | E17036030 |
| MIRROR | MIRROR GROUND | 1 EA | E17061270 |
| MIRROR | CERAMIC STAND-OFF | 4 EA | E59000002 |
| MIRROR | PLATE, SETUP SUPPRESSOR | 1 EA | E17020820 |
| MIRROR | 6-32 STANDOFF,CERAMIC, 2" L X 3/8" OD | 2 STK | E59000011 |
| MIRROR | 30KV MIRROR | 1 STK | E17002080 |
| SET-UP FARADAY | FARADAY PLATE | 1 EA | E17026610 |
| SET-UP FARADAY | FARADAY CUP | 1 EA | E17032831 |
| SET-UP FARADAY | SPACER SET UP SEAL | 2 STK | E17032810 |
| SET-UP FARADAY | BACK UP RING | 2 STK | E17037140 |
| SCANNER | PLT.SCAN,FRONT,GRND | 1 STK | E17103110 |
| SCANNER | GRAPHSCAN GRND PLATE | 1 STK | E17026680 |
| SCANNER | REAR GROUND SCAN PLATE | 1 STK | E17026690 |
| SCANNER | SCAN WING | 1 EA | E17026720 |
| SCANNER | CERAMIC STANDOFF | 2 EA | E59000010 |
| SCANNER | SCAN PLATE | 1 EA | E17026680 |
| SCANNER | REAR GRND SCAN PLT | 1 EA | E17026690 |
| SCANNER | REAR GRND SCAN PLATE | 1 EA | E17026690 |
| NEUTRAL DUMP | BEAM, STOP, NEUTRAL, DUMP | 1 EA | E17106820 |
| POST-SCAN CHAMBER | APERTURE,POST SCAN | 1 STK | E17045790 |
| POST-SCAN CHAMBER | GRAPHITE SCREW | 4 STK | E17046560 |
| DIPOLE LENS | DIPOLE INNER GRAPHITE | 6 EA | E17036410 |
| DIPOLE LENS | LINER, VERTICAL SUPPORT, DIPOLE | 6 STK | E17036400 |
| DIPOLE LENS | SST FLH VNTD SCRW, 4-40 X .375 LG | 24 STK | E47000109 |
| DIPOLE LENS | APERTURE,DIPOLE-EXIT | 1 STK | E17039040 |
| TARGET CHAMBER | TARGET ENTRANCE | 1 STK | E17024181 |
| TARGET CHAMBER | SHIELD BEAM TARGET ENTRANCE | 1 STK | E17140800 |
| TARGET CHAMBER | SHIELD SIDE WALL(E/S) | 2 STK | E17120450 |
| TRAVELING FARADAY | SHIELD TRAVELING FARADAY | 1 STK | E17156050 |
| TRAVELING FARADAY | INSULATOR, TRAVELING FARADAY | 1 STK | E17156061 |
| TRAVELING FARADAY | CUP SHIELD TRAVELING FARADAY | 1 STK | E17122180 |
| TRAVELING FARADAY | INSULATOR FOR FARADAY | 1 STK | E17008110 |
| TRAVELING FARADAY | INSULATOR | 1 STK | E17008110 |
| TRAVELING FARADAY | INSULATOR TRAV FARADAY | 1 STK | E17156060 |
| TRAVELING FARADAY | INSULATOR MULTI-FARADAY | 1 STK | E17105320 |
| FOCUS FARADAY | GATE FOCUS FARADAY, SHIELD | 1 STK | E17123500 |
| FOCUS FARADAY | FOCUS FARADAY PLATE | 1 STK | E17023050 |
| FOCUS FARADAY | FOCUS CUP, 3 POSITION | 1 STK | E17336430 |
