SEN,AXCELIS GSD 200MM HIGH CURRENT Consumables

Product Detail

Category	Description	Qty	OEM No.
ELS2 SOURCE ASSEMBLY	ARC SLIT, T15, MO	1 EA	17230100
ELS2 SOURCE ASSEMBLY	REPELLER, NO HOLE, W	1 EA	PLANSEE DESIGN
ELS2 SOURCE ASSEMBLY	REPELLER INSULATOR	1 STK	17121850
ELS2 SOURCE ASSEMBLY	REPELLER SCREW	1 EA	17121770
ELS2 SOURCE ASSEMBLY	MO INNER CUP SHIELD EGN-21750	1 EA	17121750
ELS2 SOURCE ASSEMBLY	INNER CUP SHIELD, PAS GSD	1 STK	17121750
ELS2 SOURCE ASSEMBLY	INNER CUP SHIELD, PAS GSD	1 STK	17121750
ELS2 SOURCE ASSEMBLY	INNER CUP SHIELD	1 EA	17121750
ELS2 SOURCE ASSEMBLY	ARC CHAMBER	1 EA	17133400
ELS2 SOURCE ASSEMBLY	SPACER, SHOULDER SCREW	4 EA	17128230
ELS2 SOURCE ASSEMBLY	SPRING, SHOULDER SCREW	4 EA	4001166
ELS2 SOURCE ASSEMBLY	ROD, RETAINING TA	4 EA	17036440
ELS2 SOURCE ASSEMBLY	SPACER, RETAINING ROD	4 EA	17124410
ELS2 SOURCE ASSEMBLY	HEAT SHIELD ELS	1 STK	17142660
ELS2 SOURCE ASSEMBLY	SOCKET JOINT	3 EA	17033150
ELS2 SOURCE ASSEMBLY	FLANGE SEAL	3 EA	17033150
ELS2 SOURCE ASSEMBLY	SPRING, COMPRESSION	3 EA	17033140
ELS2 SOURCE ASSEMBLY	SPRING, COMPRESSION	3 EA	17033140
ELS2 SOURCE ASSEMBLY	SPRING COMPRESSION	3 STK	17033140
ELS2 SOURCE ASSEMBLY	SPRING COMPRESSION SOURCE	3 STK	17270640
ELS2 SOURCE ASSEMBLY	BALL JOINT	3 EA	17033160
ELS2 SOURCE ASSEMBLY	BALL SEAL, CERAMIC	3 EA	17033160
ELS2 SOURCE ASSEMBLY	SPRING, RETAINING ROD	4 EA	4000059
ELS2 SOURCE ASSEMBLY	SPACER, RETAINING ROD	4 EA	17124410
ELS2 SOURCE ASSEMBLY	NUT PLATE, MOLY ELS	1 EA	17189140
ELS2 SOURCE ASSEMBLY	SCREW, ARC CHAMBER MOUNT	4 EA	17127640
ELS2 LINERED SOURCE ASSEMBLY	MO - CATHODE LINER	1 EA	17292620
ELS2 LINERED SOURCE ASSEMBLY	W-LINER CATHODE	1000 ST	17292620
ELS2 LINERED SOURCE ASSEMBLY	WL STIRNPLATTE ELS	1000 ST	17292620
ELS2 LINERED SOURCE ASSEMBLY	MOLY LINER, CATHODE	1 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, CATH END, W	1 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, CATH END, MO	1 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	MO - LINER SIDE	2 EA	17292610
ELS2 LINERED SOURCE ASSEMBLY	W-LINER SIDE	2 STK	17292610
ELS2 LINERED SOURCE ASSEMBLY	LINER SIDE	2 STK	170113550
ELS2 LINERED SOURCE ASSEMBLY	LINER SIDE	2 STK	170113550
ELS2 LINERED SOURCE ASSEMBLY	LINER SIDE	2 STK	170113550
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, SIDE, W, VAP	2 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, SIDE, MO, NV	2 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, SIDE, W, NV	2 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	MO ARC CHAMBER ASSY	1 EA	17292590
ELS2 LINERED SOURCE ASSEMBLY	W BODY,A/C LINER VERSION	1 STK	17292590
ELS2 LINERED SOURCE ASSEMBLY	~WL10 KAMMER	1000 ST	17292590
ELS2 LINERED SOURCE ASSEMBLY	A/C BODY, ELS, REINFORCED, VAP	1000 ST	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	CATHODE SLEEVE LINER	1 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	CATHODE SLEEVE LINER	1 AS	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	CATHODE SLEEVE LINER	1 AS	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, BASE, W	1 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, BASE, MO	1 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	MO - LINER BOTTOM	1 STK	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	W - LINER BOTTOM	1 EA	17292600
ELS2 LINERED SOURCE ASSEMBLY	WL10 - LINER BOTTOM	1000 ST	17292600
ELS2 LINERED SOURCE ASSEMBLY	MO - REPELLER LINER	1000 ST	17292630
ELS2 LINERED SOURCE ASSEMBLY	W REPELLER LINER	1 EA	17292630
ELS2 LINERED SOURCE ASSEMBLY	WL-REPELLER LINER	1000 ST	17292630
ELS2 LINERED SOURCE ASSEMBLY	MO ELS LINER,REPELLER	1 STK	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, REP END, MO,1	1 EA	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	LINER, ELS, REP END, W, 1	1 STK	PLANSEE DESIGN
ELS2 LINERED SOURCE ASSEMBLY	TZM MOLY LINER,NV ELS
ELS2 LINERED SOURCE ASSEMBLY
ELS2 LINERED SOURCE ASSEMBLY
ELS2 SOURCE CHAMBER OPTIONS	ARC CHAMBER	1 EA	17133400
ELS2 SOURCE CHAMBER OPTIONS	BODY, ARC CHAMBER (ELS)	1 EA	PLANSEE DESIGN
ELS2 SOURCE CHAMBER OPTIONS	BODY, ARC CHAMBER (ELS)	1 EA	17133310
ELS2 SOURCE CHAMBER OPTIONS	MO 2-39.268 A VAR. 1 KAMMER	1 EA	17235720
ELS4 LINERED SOURCE ASSEMBLY	GSD ARC SLIT ELS	1 STK	170166374
ELS4 LINERED SOURCE ASSEMBLY	GSD ARC SLIT ELS	1 STK	170166374
ELS4 LINERED SOURCE ASSEMBLY	LINER REPELLER ELS	1 STK	170164933
ELS4 LINERED SOURCE ASSEMBLY	LINER REPELLER ELS	1 STK	170164933
ELS4 LINERED SOURCE ASSEMBLY	LINER SIDE ELS	2 STK	170158782
ELS4 LINERED SOURCE ASSEMBLY	LINER SIDE ELS	2 STK	170158782
ELS4 LINERED SOURCE ASSEMBLY	GRAPHITE STDTXT SPACER LINER	1 STK	170158894
ELS4 LINERED SOURCE ASSEMBLY	STDNTXT CHAMBER ARC ELS	1 STK	170166900
ELS4 LINERED SOURCE ASSEMBLY	INSERT CATHODE HOLE ELS	1 STK	170164934
ELS4 LINERED SOURCE ASSEMBLY	LINER CATHODE ELS	1 STK	170158780
ELS4 LINERED SOURCE ASSEMBLY	LINER CATHODE ELS	1 STK	170158780
ELS4 LINERED SOURCE ASSEMBLY	LINER BACK ELS	1 STK	170158783
ELS4 LINERED SOURCE ASSEMBLY	LINER BACK ELS	1 STK	170158783
ELS2 FILAMENT ASSEMBLY	SST BHCS .250LG	1 EA	4400008
ELS2 FILAMENT ASSEMBLY	SST WASHER, FLAT, #6	1 EA	N/A
ELS2 FILAMENT ASSEMBLY	SUPPORT PLATE, REVERSIBLE	1 EA	PLANSEE DESIGN
ELS2 FILAMENT ASSEMBLY	FILAMENT ELS ASSY	1 EA	PLANSEE DESIGN
ELS2 FILAMENT ASSEMBLY	CATHODE, ELS2	1 EA	17246790
ELS2 FILAMENT ASSEMBLY	CATHODE REPELLER	1 EA	17133340
ELS2 FILAMENT ASSEMBLY	SHCS, 6-32, .375LG, SST	2 EA	4400044
ELS2 FILAMENT ASSEMBLY	SST WASHER, FLAT, #6 SP	2 EA	4400232
ELS2 FILAMENT ASSEMBLY	INSULATOR, CATHODE	1 EA	17287870
ELS2 FILAMENT ASSEMBLY	SST SHCS .750 LG	2 EA	4400842
ELS2 FILAMENT ASSEMBLY	CATHODE WIRE	1 EA	17156990
ELS2 FILAMENT ASSEMBLY	FILAMENT FEED STRAP	2 EA	17133300
ELS2 FILAMENT ASSEMBLY	SST, SHCSV .375LG	2 EA	4400743
ELS2 FILAMENT ASSEMBLY	WASHER, SST FLAT	6 EA	4400007
ELS2 FILAMENT ASSEMBLY	SST LOCK WASHER	2 EA	4400041
ELS2 FILAMENT ASSEMBLY	SCREW, SST BHCS .375LG	4 EA	PLANSEE DESIGN
ELS2 FILAMENT ASSEMBLY	SST SHCS .625LG	4 EA	4400061
ELS2 FILAMENT ASSEMBLY	WASHER, SPLT LOCK	6 EA	4400034
ELS2 FILAMENT ASSEMBLY	FIL. CLAMP, ELS2, SCREW	2 EA	17335310
FILAMENT OPTIONS	FILAMENT, ELS, STRAIGHT LEG	1 EA	17C2984
FILAMENT OPTIONS	FILAMENT, ELS, ASSY	1 STK	17C2984
FILAMENT OPTIONS	WVM/TA FILAMENT	1000 ST	17C2984
FILAMENT OPTIONS	FILAMENT VHE	1 EA	17254850
FILAMENT OPTIONS	FILAMENT ELS ASSY	1 EA	17189120
FILAMENT OPTIONS	FILAMENT, ELS2	1 EA	17287851
FILAMENT OPTIONS	FILAMENT, ELS, ASSY	1000 ST	17287851
FILAMENT OPTIONS	WVM/TA WENDEL 41.926/000/B D1/	1 EA	17287851
FILAMENT OPTIONS	ELS FILAMENT	1 STK	PLANSEE DESIGN
FILAMENT OPTIONS	FILAMENT, ELS, STRAIGHT	1 EA	17287850
FILAMENT OPTIONS	FILAMENT ELS ASSY	1 EA	17287850
FILAMENT OPTIONS	FILAMENT, ELS, ASSY	1 STK	17287850
FILAMENT OPTIONS	CATHODE WIRE	1 EA	17156990
FILAMENT OPTIONS	CATHODE / ARC WIRE ELS	1 STK	17156990
CATHODE OPTIONS	CATHODE, ELS	1 EA	17142890
CATHODE OPTIONS	CATHODE, ELS2	1 EA	17142890
CATHODE OPTIONS	CATHODE ASSY	1 STK	17142890
CATHODE OPTIONS	CATHODE ASSY # 4	1 STK	17142890
CATHODE OPTIONS	CATHODE SUB AS	1 EA	1724679
CATHODE OPTIONS	CATHODE, ELS	1 EA	17158000
CATHODE OPTIONS	CATHODE ASSY TUNGSTEN	1 STK	17158000
CATHODE OPTIONS	CATHODE, ELS, CAN STYLE	1 EA	17158000
CATHODE OPTIONS	CATHODE ETERNA	1 EA	17355270
CATHODE OPTIONS	CATHODE W 6MM	1 STK	PLANSEE DESIGN
CATHODE OPTIONS	CATHODE, ELS, CAN STYLE, SMALL DIA.	1 EA	170093650
CATHODE OPTIONS	CATHODE REPELLER	1 EA	17121930
CATHODE OPTIONS	TZM-CATHODE REPELLER	1 EA	17121930
CATHODE OPTIONS	CATHODE REPELLER	1 EA	17121930
CATHODE OPTIONS	WL-CATHODE REPELLER	1000 ST	17121930
CATHODE OPTIONS	CATHODE REPELLER	1 STK	17355290
CATHODE OPTIONS	CATHODE REPELLER,THREADCOVER	1 EA	17121930
GSD REPELLER OPTIONS	REPELLER	1 EA	17121740
GSD REPELLER OPTIONS	REPELLER	1 STK	17121740
GSD REPELLER OPTIONS	WL10 TIEGEL	1000 ST	17121740
GSD REPELLER OPTIONS	MO TIEGEL	1000 ST	17121740
GSD REPELLER OPTIONS	REPELLER	1 STK	PLANSEE DESIGN
GSD REPELLER OPTIONS	REPELLER, MOD, 15MM	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS	ARC SLIT, T15, MO	1 EA	17230100
ARC SLIT OPTIONS	ARC SLIT T15 TYPE # 5	1 STK	17230100
ARC SLIT OPTIONS	ARC SLIT, T15, W	1 EA	17230090
ARC SLIT OPTIONS	WL 3-40.008 C VAR.2 ARC SLIT	1000 ST	17230090
ARC SLIT OPTIONS	ARC SLIT, 15R, MO	1 EA	17128110
ARC SLIT OPTIONS	ARC SLIT, 15R, W	1 EA	17129020
ARC SLIT OPTIONS	ARC SLIT, 20R, MO	1 EA	17165580
ARC SLIT OPTIONS	W ARC SLIT 20R	1 STK	17165810
ARC SLIT OPTIONS	WL ARC SLIT 20R	1 STK	17165810
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	ARC SLIT SHIM T15 TEXTURED	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM, 2 PIECE ARC SLIT, T15, MO	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM, 2 PIECE ARC SLIT, T15	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM 2PIECE ARC SLIT T15	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	T15 GPH BTM, 2-PIECE	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	MO SHIM, 2PCE ARC SLIT, R15, PAS GSD	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM, 2PC ARC SLIT, R15, PAS, GSD	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM 2PCE ARC SLIT R15 PAS GSD	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	TOP, 2 PIECE ARC SLIT, T15, MO	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	TOP, 2 PIECE ARC SLIT, T15, W	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	TOP, 2 PIECE ARC SLIT, T15,W	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	TOP, 2 PIECE ARC SLIT, T15, GPH	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	TOP PLATE, 2PC, 20R	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	TOP PLATE, TUNGSTEN, 2-PIECE, 20R	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	TOP, 2 PIECE ARC SLIT, 20R, GPH	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM, 2PC ARC SLIT, 20R	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM, 2PC ARC SLIT, 20R	1 STK	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM, 2PC ARC SLIT, 20R	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	SHIM, TUNGSTEN, 2-PIECE, 20R MOD	1 EA	PLANSEE DESIGN
ARC SLIT OPTIONS - 2 PC.   MODIFICATIONS	TOP, 2PCE ARC SLIT, R15, PAS GSD	1 STK	PLANSEE DESIGN
VAPORIZER COMPONENTS	VAPORIZER CRUCIBLE	1 EA	17033380
VAPORIZER COMPONENTS	SB VAPORIZER CR	1 STK	1712960
VAPORIZER COMPONENTS	VAPORIZER NOZZLE	1 STK	17088430
VAPORIZER COMPONENTS	VAPORIZER NOZZLE	1 STK	1706370
VAPORIZER COMPONENTS	VAPORIZER NOZZLE	1 EA	17049140
VAPORIZER COMPONENTS	VAP. RETAINER	1 EA	17355000
VAPORIZER COMPONENTS	VAP. TUBE, GRAPHITE	1 EA	17355010
VAPORIZER COMPONENTS	VAP. NOZZLE	1 EA	17354990
VAPORIZER COMPONENTS	VAPORIZER CAP	1 EA	17036190
VAPORIZER COMPONENTS	NOZZLE RETAINER	1 EA	17D1284
SOURCE MOUNTING FLANGE   ASSEMBLY	PLT SHIELD SCE	1 EA	17083680
SOURCE MOUNTING FLANGE   ASSEMBLY	SHIELD PLATE	1 STK	17122511
SOURCE MOUNTING FLANGE   ASSEMBLY	SOURCE SHIELD PLATE	1 EA	17338530
SOURCE MOUNTING FLANGE   ASSEMBLY	CATHODE ARC PLATE	2 EA	17037280
SOURCE MOUNTING FLANGE   ASSEMBLY	W CATHODE ARC PLATE	2 EA	PLANSEE DESIGN
SOURCE HOUSING ASSEMBLY	SHIELD, CLAMP RING	1 EA	17128740
SOURCE HOUSING ASSEMBLY	SHIELD, SOURCE	1 EA	17139160
EXTRACTION ASSEMBLY 33	6-32 GRAPHITE SCREW, .158 LONG	8 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 33	MESH, BOTTOM, QUANTUM	2 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 33	PLATE, SUPP ELECTRODE, WIRE MESH	2 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 33	MANIPULATOR ARM, ELECTRODE, R.H.	1 EA	17133800
EXTRACTION ASSEMBLY 33	FEED THRU SHIELD	2 EA	17254980
EXTRACTION ASSEMBLY 33	FEEDTHRU, HIGH VOLTAGE	2 EA	17254970
EXTRACTION ASSEMBLY 33	CERAMIC STANDOFF	2 EA	5001608
EXTRACTION ASSEMBLY 33	LONG ELECTRODE SHIELD	6 EA	17170070
EXTRACTION ASSEMBLY 33	SUPPORT, ELECTRODE	1 STK	17133741
EXTRACTION ASSEMBLY 33	ELECTRODE SPACER	6 EA	17170060
EXTRACTION ASSEMBLY 33	RING, FIELD	2 EA	17170050
EXTRACTION ASSEMBLY 33	CERAMIC STANDOFF	6 EA	17170080
EXTRACTION ASSEMBLY 33	ELECTRODE SUPPORT SHIELD	1 EA	PLANSEE DESIGN
EXTRACTION ASSEMBLY 33	SUPPORT, ELECTRODE	1 STK	17133740
EXTRACTION ASSEMBLY 33	ELECTRODE SUPPORT, MOUNTING	1 STK	17133740
EXTRACTION ASSEMBLY 33	ELECTRODE SUPPORT, ECCENTRIC	1 STK	17133740
EXTRACTION ASSEMBLY 33	SST, 8-32, HEX NUT	1 EA	17133740
EXTRACTION ASSEMBLY 33	BOTTOM ELECTRODE MOUNT PLATE	2 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 33	SIDE PLATE	2 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 33	MANIPULATOR ARM, ELECTRODE, L.H.	1 EA	17133790
EXTRACTION ASSEMBLY 33	SHIELD, INSULATOR	2 EA	17147950
EXTRACTION ASSEMBLY 33	EXTRACTION ELEC. PLATE	2 EA	17170020
EXTRACTION ASSEMBLY 33	1ROUND ELECTRODE, PLATE	2 EA	17170030
EXTRACTION ASSEMBLY 33	ELECTRODE, GROUND	2 EA	17132290
EXTRACTION ASSEMBLY 33	ELECTRODE, GROUND	2 STK	17132290
EXTRACTION ASSEMBLY 33	ELECTRODE, GROUND	2 EA	17132290
EXTRACTION ASSEMBLY 33	ELECTRODE, GROUND	2 EA	17132290
EXTRACTION ASSEMBLY 33	SUPPRESSION ELECTRODE	2 EA	17170040
EXTRACTION ASSEMBLY 33	ELECTRODE, SUPPRESSION	2 EA	17170040
EXTRACTION ASSEMBLY 33	ELECTRODE, SUPPRESSION	2 EA	17170040
EXTRACTION ASSEMBLY 33	SUPPRESSION ELECTRODE	2 EA	17170040
EXTRACTION ASSEMBLY 33	ELECTRODE, SUPPRESSION	2 EA	17170040
EXTRACTION ASSEMBLY 33	ELECTRODE, SUPPRESSION	2 EA	17170040
EXTRACTION ASSEMBLY 34	ELECTRODE, SUPPRESSION	2 EA	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	EXTRACTION ELECTRODE PLT	2 EA	17192410
EXTRACTION ASSEMBLY 34	ELECTRODE, GROUND	1 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	GROUND ELECTRODE PLATE	2 EA	17192420
EXTRACTION ASSEMBLY 34	MANIPULATOR ARM, ELECTRODE, R.H.	1 EA	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	ELECTRODE SUPPORT, ECCENTRIC	1 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	SST, 8-32, HEX NUT	1 EA
EXTRACTION ASSEMBLY 34	ELECTRODE SUPPORT, MOUNTING	1 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	SST FSV .500LG	2 EA
EXTRACTION ASSEMBLY 34	BHCS, VENTED, 6-32, .625, MO COATED	3 EA
EXTRACTION ASSEMBLY 34	ELECTRODE SUPPORT SHIELD	1 EA	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	SUPPORT, ELECTRODE	1 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	CERAMIC STAND OFF	6 EA	17192380
EXTRACTION ASSEMBLY 34	LONG ELECTRODE SHIELD	6 EA	17192400
EXTRACTION ASSEMBLY 34	SPACER, GROUND V34	6 EA	17192390
EXTRACTION ASSEMBLY 34	RING, FIELD	2 EA	17192430
EXTRACTION ASSEMBLY 34	FLAT HEAD, SST SCREW, 4-40 X .250	4 STK
EXTRACTION ASSEMBLY 34	BOTTOM ELECTRODE MOUNT PLATE	2 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	SIDE PLATE	2 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	SST WASHER, FLAT, M4	4 EA
EXTRACTION ASSEMBLY 34	BHCS, 8-32, .625, SST	4 STK
EXTRACTION ASSEMBLY 34	632 BHCSO, VENTED, .250LG	3 EA
EXTRACTION ASSEMBLY 34	SST WASHER, FLAT, #6 SP	15 EA	4400232
EXTRACTION ASSEMBLY 34	SUPPRESSION STRAP V34	1 EA	17251090
EXTRACTION ASSEMBLY 34	SHIELD, INSULATOR	2 EA	17147950
EXTRACTION ASSEMBLY 34	CERAMIC STANDOFF	2 EA	5001608
EXTRACTION ASSEMBLY 34	6-32 SOCKET HEAD CAP	2 STK
EXTRACTION ASSEMBLY 34	THREAD. LOCATION PIN GSD EXTRAC.	2 STK
EXTRACTION ASSEMBLY 34	MANIPULATOR ARM, ELECTRODE, L.H.	1 EA	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	FEED THRU SHIELD	2 EA	17254980
EXTRACTION ASSEMBLY 34	FEEDTHRU, HIGH VOLTAGE	2 EA	17254970
EXTRACTION ASSEMBLY 34	GSD EXT.TOP, COVER, FEEDTHRU-	1 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	6-32 BHCSO, VENTED, .500LG	3 STK
EXTRACTION ASSEMBLY 34	SUPPORT, ELECTRODE	1 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	GSD EXTRACTION BOTTOM, COVER	1 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	SST FLHSOV .375 LG	5 STK
EXTRACTION ASSEMBLY 34	18-8 SST,#1/4-20 X .500,VNTD, FL HEAD	2 STK
EXTRACTION ASSEMBLY 34	ELECTRODE MOUNTING PLATE NUT	4 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	SHOULDER SCRW, LOWER & UPPER	4 STK	PLANSEE DESIGN
EXTRACTION ASSEMBLY 34	SCREW, 440, FLAT HEAD, VENTED, 375	6 EA
EXTRACTION ASSEMBLY 34	SOCKET HEAD, FLAT, 8-32, .625 LG	24 STK
EXTRACTION ASSEMBLY 34	SCREW, 4-40, PHSL, .250LG, SST	6 STK
ANALYZER VERSION 1	EXTENSION TUBE	1 EA	17122930
ANALYZER VERSION 1	EXIT LINER	1 EA	17122910
ANALYZER VERSION 1	SHIELD, EXIT, LONG	1 EA	PLANSEE DESIGN
ANALYZER VERSION 1	GRAPHITE SHIELD	1 EA	17099631
ANALYZER VERSION 1	SOURCE EXIT APERTURE	1 EA	17208240
ANALYZER VERSION 1	BEAM DEFINING APERTURE	1 EA	17131610
ANALYZER VERSION 1	LINER, VG PUMP HSG	1 EA	17236730
ANALYZER VERSION 1	PUMP HOUSING LINER	1 EA	PLANSEE DESIGN
ANALYZER VERSION 1	LINER, VG PUMP	1 EA	17236740
ANALYZER VERSION 2	EXTENSION TUBE	1 EA	17122930
ANALYZER VERSION 2	EXIT LINER	1 EA	17122910
ANALYZER VERSION 2	SHIELD, EXIT, LONG	1 EA	PLANSEE DESIGN
ANALYZER VERSION 2	GRAPHITE SHIELD	1 EA	17099631
ANALYZER VERSION 2	SOURCE EXIT APERTURE	1 EA	17208240
ANALYZER VERSION 2	BEAM DEFINING APERTURE	1 EA	17131610
ANALYZER VERSION 2	OUTER BEAM DUMP VPI G	1 STK	N/A
ANALYZER VERSION 2	OUTER DUMP, ANALYZER EXIT SHIELD	1 EA	17122890
ANALYZER VERSION 3	EXTENSION TUBE	1 EA	17122930
ANALYZER VERSION 3	EXIT LINER	1 EA	17122910
ANALYZER VERSION 3	EXIT DUMP	1 EA	17100521
ANALYZER VERSION 3	GRAPHITE SHIELD	1 EA	17099631
ANALYZER VERSION 3	SOURCE EXIT APERTURE	1 EA	17208240
ANALYZER VERSION 3	BEAM DEFINING APERTURE	1 EA	17131610
ANALYZER VERSION 3	OUTER BEAM DUMP VPI G	1 STK	N/A
ANALYZER VERSION 3	OUTER END GRAPHITE	1 STK	17099671
ANALYZER VERSION 4	EXTENSION TUBE	1 EA	17122930
ANALYZER VERSION 4	EXIT LINER	1 EA	17122910
ANALYZER VERSION 4	SHIELD, EXIT, LONG	1 EA	PLANSEE DESIGN
ANALYZER VERSION 4	GRAPHITE SHIELD	1 EA	17099631
ANALYZER VERSION 4	SOURCE EXIT APERTURE	1 EA	17208240
ANALYZER VERSION 4	BEAM DEFINING APERTURE	1 EA	17131610
ANALYZER VERSION 4	LINER, VG MAGNET DUCT	1 EA	17233330
GSD POLE EXIT COVERS	POLE EXIT UPPER COVER	1 STK	17385970
GSD POLE EXIT COVERS	POLE EXIT LOWER COVER	1 STK	17385971
ELECTROSTATIC QUADRAPOLE	CUP SHIELD, QUAD, SMALL	24 STK	17066301
ELECTROSTATIC QUADRAPOLE	STANDOFF CERAMIC 3/8 X 5/8	24 STK	5001057
ELECTROSTATIC QUADRAPOLE	CUP SHIELD, QUAD, LARGE	24 STK	17066300
ELECTROSTATIC QUADRAPOLE	QUAD, LONG, EXIT SHIELD	4 EA	17118520
ELECTROSTATIC QUADRAPOLE	INSULATOR, CERAMIC, LONG	8 STK	17031591
ELECTROSTATIC QUADRAPOLE	INSULATOR, CERAMIC, SHORT	88 EA	17031590
ELECTROSTATIC QUADRAPOLE	QUAD, SHORT, EXIT SHIELD	44 EA	17118510
ELECTROSTATIC QUADRAPOLE	QUAD APERTURE	24 EA	17231630
GSD RESOLVING APERTURE	WINGED APERTURE	1 EA	17289500
GSD RESOLVING   "COOLED" APERTURE	RESOLVING APERTURE	1 EA	17242590
SLIT QUADRUPOLE ASSEMBLY	BEAM APERTURE	1 EA	17122970
SLIT QUADRUPOLE ASSEMBLY	MAGNET LINER	1 EA	17122960
SLIT QUADRUPOLE ASSEMBLY	BEAM APERTURE, FRAME		PLANSEE DESIGN
SLIT QUADRUPOLE ASSEMBLY	BEAM APERTURE, INSERT		PLANSEE DESIGN
SLIT QUADRUPOLE ASSEMBLY	SCREW, FH, GPH, 632, 22LG	2	PLANSEE DESIGN
SLIT QUADRUPOLE ASSEMBLY	2 PIECE BEAM APERTURE		PLANSEE DESIGN
POST ACCEL MANIPULATOR   ASSEMBLY	ELECTRODE SHIELD	1 EA	17122980
POST ACCEL MANIPULATOR   ASSEMBLY	POST ACCEL ELECTRODE	1 EA	17237140
POST ACCEL MANIPULATOR   ASSEMBLY	CERAMIC STANDOFF	4 STK	723000030038
POST ACCEL MANIPULATOR   ASSEMBLY	EXTRACTION APERTURE	1 EA	17237130
POST ACCEL MANIPULATOR   ASSEMBLY	INSULATOR SHIELD, OUTER	4 EA	1711261
POST ACCEL MANIPULATOR   ASSEMBLY	INSULATOR SHIELD, INNER	4 EA	1711262
EMER ASSEMBLY	BIAS ELECTRODE, EMER	1 EA	17138730
EMER ASSEMBLY	SHIELD, BACK, EMER	1 EA	17138740
EMER ASSEMBLY	BIAS APERTURE INSULATOR	4 EA	PLANSEE DESIGN
EMER ASSEMBLY	SHIELD, FRONT, EMER	1 EA	17138750
RESOLVING EXTENSION TUBE	RESOLVING APERTURE	1 EA	17119410
RESOLVING EXTENSION TUBE	EXTENSION TUBE	1 EA	17119351
RESOLVING EXTENSION TUBE	BEAM APERTURE	1 EA	17126830
ELECTRON SHOWER ASSEMBLY	LINER, E-SHOWER	1 EA	17135440
ELECTRON SHOWER ASSEMBLY	TUBE INSULATOR	4 EA	17109910
ELECTRON SHOWER ASSEMBLY	BSHG SNAP INSULATOR	4 EA	17109340
ELECTRON SHOWER ASSEMBLY	SHCS, 6-32, .375LG, SST	4 EA	4400044
ELECTRON SHOWER ASSEMBLY	HOUSING LINER	1 EA	17113980
ELECTRON SHOWER ASSEMBLY	SHCS, 6-32, .25LG, SST	2 EA	4400216
ELECTRON SHOWER ASSEMBLY	APERTURE	1 EA	17121720
ELECTRON SHOWER ASSEMBLY	APERTURE INSULATOR	1 EA	17116930
ELECTRON SHOWER ASSEMBLY	GSD, INSULATOR	3 EA	17A7036
ELECTRON SHOWER ASSEMBLY	FILAMENT APERTURE	1 EA	17021870
ELECTRON SHOWER ASSEMBLY	ELECTRON SHOWER FILAMENT	1 EA	1909360
ELECTRON SHOWER ASSEMBLY	E-SHWR FILAMENT INSULATOR	1 EA	17164510
ELECTRON SHOWER ASSEMBLY	FEED THRU	2 EA	17A0732
ELECTRON SHOWER ASSEMBLY	INSULATOR, FEEDTHRU, E-SHOWER	2 EA	17S4891
ELECTRON SHOWER ASSEMBLY	O RING I.D. 6.725	1 EA	3500028
ELECTRON SHOWER ASSEMBLY	FEEDTHRU INSULATOR	2 EA	17S4889
ELECTRON SHOWER ASSEMBLY	NUT, 10-32 UNF, SEF FEED THRU	2 EA	17S1354
GSD ELECTRON SHOWER ASSEMBLY	SST, 6-32 SCREW, SHC, .500 LG, MOS2	16 EA	4400100
GSD ELECTRON SHOWER ASSEMBLY	WASHER, SPLT LOCK	12 EA	4400034
GSD ELECTRON SHOWER ASSEMBLY	BSHG SNAP INSULATOR	4 EA	17109340
GSD ELECTRON SHOWER ASSEMBLY	LINER, E-SHOWER	1 EA	17135440
GSD ELECTRON SHOWER ASSEMBLY	SHCS, 6-32, .25LG, SST	3 EA	4400216
GSD ELECTRON SHOWER ASSEMBLY	EFS TUBE	1 EA	17164580
GSD ELECTRON SHOWER ASSEMBLY	APERTURE, ENTRANCE	1 EA	17173230
GSD ELECTRON SHOWER ASSEMBLY	SCREW, BHSOV, 2-56, .250LG, SST	2 STK	4400202
GSD ELECTRON SHOWER ASSEMBLY	E-SHOWER APERTURE	1 EA	17165510
GSD ELECTRON SHOWER ASSEMBLY	E.SHOWER BIAS APERTURE	1 EA	17164520
GSD ELECTRON SHOWER ASSEMBLY	SCREW, SHC, 2-56, .750LG, SST	2 STK
GSD ELECTRON SHOWER ASSEMBLY	ELECTRON SHOWER FILAMENT	1 EA	1909360
GSD ELECTRON SHOWER ASSEMBLY	E-SHOWER FIL. INSULATOR	1 EA	17321470
GSD ELECTRON SHOWER ASSEMBLY	FILAMENT INSULATOR HBC GRADE	1 STK	17321470
GSD ELECTRON SHOWER ASSEMBLY	O RING I.D. 6.725	1 EA	3500028
GSD ELECTRON SHOWER ASSEMBLY	440, SHCS, .250, SST, VENTED	6 EA	4400424
GSD ELECTRON SHOWER ASSEMBLY	PLATE	2 STK	17A0830
GSD ELECTRON SHOWER ASSEMBLY	FEED THRU	2 EA	17S1597
GSD ELECTRON SHOWER ASSEMBLY	NUT, 10-32 UNF, SEF FEED THRU	2 EA	17S1354
GSD ELECTRON SHOWER ASSEMBLY	FEEDTHRU INSULATOR	2 EA	17S4889
GSD ELECTRON SHOWER ASSEMBLY	INSULATOR, FEEDTHRU, E-SHOWER	2 EA	17S4891
GSD ELECTRON SHOWER ASSEMBLY	FEED THRU	2 EA	17A0732
GSD ELECTRON SHOWER ASSEMBLY	ORING .354ID	4 EA	3500068
GSD ELECTRON SHOWER ASSEMBLY	SST WASHER, FLAT, #8 SP	4 EA	4400122
GSD ELECTRON SHOWER ASSEMBLY	WASHER, SPLIT	4 STK	4400062
GSD ELECTRON SHOWER ASSEMBLY	8-32, SOCKET HEAD SCREW, .750 LG	4 STK	4400057
GSD ELECTRON SHOWER ASSEMBLY	SST 4-40 SHCO .188LG	2 EA	1231200403
GSD ELECTRON SHOWER ASSEMBLY	SST FLAT WASHER	2 EA	460000105
GSD ELECTRON SHOWER ASSEMBLY	SCREW, 440, SET, .313LG, SST	7 STK
GSD ELECTRON SHOWER ASSEMBLY	440, BHCS, .750, SST, VENTED	2 STK	E47000006
GSD ELECTRON SHOWER ASSEMBLY	TUBE INSULATOR	4 EA	17109910
FLAG FARADAY ASSEMBLY 1	BURN THRU PLATE	1 EA	1766531
FLAG FARADAY ASSEMBLY 1	INSULATOR	2 STK	1744570
FLAG FARADAY ASSEMBLY 1	STRIKE PLATE	6 EA	17099201
FLAG FARADAY ASSEMBLY 1	SMALL SHIELD	1 EA	17100461
FLAG FARADAY ASSEMBLY 1	APERTURE, FARADAY	1 EA	17099181
FLAG FARADAY ASSEMBLY 1	SST BHCS .375LG	4 EA	4400183
FLAG FARADAY ASSEMBLY 1	FARADAY SHIELD	1 EA	17099831
FLAG FARADAY ASSEMBLY 1	INSULATING WASHER	2 STK	1744690
FLAG FARADAY ASSEMBLY 2	PLATE STRIKER FARADAY V.G.	6 STK	17066871
FLAG FARADAY ASSEMBLY 2	SHIELD, GRAPH, INJECTOR	1 EA	17065341
FLAG FARADAY ASSEMBLY 2	STRIKE PLATE, SERRATED	1 STK	17319860
FLAG FARADAY ASSEMBLY 2	STRIKE PLATE, MOD 1	1 STK	PLANSEE DESIGN
FLAG FARADAY ASSEMBLY 2	STRIKE PLATE, MOD 2	2 STK	PLANSEE DESIGN
FLAG FARADAY ASSEMBLY 2	SPACER GRAPHITE RING WITH LIP	1 STK	PLANSEE DESIGN
FARADAY STRIKE PLATES	STRIKE PLATE 1 DISK FARADAY	1 STK	17182570
FARADAY STRIKE PLATES	STRIKE PLATE 2 DISK FARADAY	1 STK	17182580
FARADAY STRIKE PLATES	STRIKE PLATE 3 DISK FARADAY	1 STK	17182590
FARADAY STRIKE PLATES	STRIKE PLATE 4 DISK FARADAY	1 STK	17182600
