| Category | Description | Qty | OEM No. |
| 810 BERNAS SOURCE | SIDE PLATE, W/GAS NOZZLE, BERNAS | 1 EA | E17094441 |
| 810 BERNAS SOURCE | SIDE PLATE, BERNAS ARC CHAMBER | 1 STK | E17067001 |
| 810 BERNAS SOURCE | FILAMENT BERNAS ARC SOURCE | 2 STK | E17069340 |
| 810 BERNAS SOURCE | END PLATE, BERNAS | 1 EA | E17094421 |
| 810 BERNAS SOURCE | REFLECTOR, THREADED | 1 EA | E17120300 |
| 810 BERNAS SOURCE | INSULATOR, OUTER | 2 EA | E17124440 |
| 810 BERNAS SOURCE | INSULATOR, INNER BERNAS | 2 EA | E17124430 |
| 810 BERNAS SOURCE | FILAMENT INSULATOR | 2 EA | E17132320 |
| 810 BERNAS SOURCE | FILAMENT CLAMP | 2 EA | E17132290 |
| 810 BERNAS SOURCE | GAS FEED TUBE | 2 EA | E17132280 |
| 810 BERNAS SOURCE | RETAINER HOOK | 2 EA | E17121520 |
| 810 BERNAS SOURCE | BASE PLATE, BERNAS A/C | 4 EA | E17131210 |
| 810 BERNAS SOURCE | INSULATOR, FILAMENT, BERNAS | 8 EA | E17092410 |
| 810 BERNAS SOURCE | ARC CHAMBER TOP | 4 EA | E17092400 |
| 810 BERNAS SOURCE | GRAPHITE INSERT | 1 EA | E17094401 |
| 810 BERNAS SOURCE | BAFFLE, INNER INSULATOR | 4 EA | E17077001 |
| 810 BERNAS LINER SOURCE | A/C SUPPORT PLATE | 1 EA |
|
| 810 BERNAS LINER SOURCE | GAS FEED RETAINER | 1 EA |
|
| 810 BERNAS LINER SOURCE | GAS FEED TUBE | 1 EA |
|
| 810 BERNAS LINER SOURCE | GAS NOZZLE | 1 EA |
|
| 810 BERNAS LINER SOURCE | END LINER TEXTURED | 2 EA |
|
| 810 BERNAS LINER SOURCE | SIDE LINER W/ NOZ TEXTURED | 1 EA |
|
| 810 BERNAS LINER SOURCE | VIISTA A/C TOP | 1 EA |
|
| 810 BERNAS LINER SOURCE | VIISTA A/C TOP SHIM | 1 EA |
|
| 810 BERNAS LINER SOURCE | SIDE LINER TEXTURED | 1 EA |
|
| 810 BERNAS LINER SOURCE | BASE LINER, VAP. | 1 EA |
|
| 810 BERNAS LINER SOURCE | INSULATOR, CAPTIVE, VIISION | 4 EA |
|
| 810 BERNAS LINER SOURCE | VAPORIZER NOZZLE | 2 EA |
|
| 810 BERNAS LINER SOURCE | SOLID CHBR, CAPTIVE INSUL. | 1 EA |
|
| 810 BERNAS LINER SOURCE | SOLID CHBR, CAPTIVE INSUL. | 1 EA |
|
| 810 BERNAS LINER SOURCE | BASE LINER | 1 EA |
|
| 810 BERNAS LINER OPTIONS | END LINER | 2 EA |
|
| 810 BERNAS LINER OPTIONS | SIDE LINER W/NOZZLE | 1 EA |
|
| 810 BERNAS LINER OPTIONS | SIDE LINER | 1 EA |
|
| 810 BERNAS LINER OPTIONS | BASE LINER, VAP. | 1 EA |
|
| 810 BERNAS LINER OPTIONS | BASE LINER | 1 EA |
|
| 810 BERNAS LINER OPTIONS | END LINER TEXTURED | 1 EA |
|
| 810 BERNAS LINER OPTIONS | SIDE LINER W/ NOZ TEXTURED | 1 EA |
|
| 810 BERNAS LINER OPTIONS | SIDE LINER TEXTURED | 4 EA |
|
| 810 BERNAS LINER OPTIONS | BASE LINER TEXTURED, VAP | 1 EA |
|
| 810 BERNAS LINER OPTIONS | BASE LINER TEXTURED, NON-VA | 1 EA |
|
| 810/900 IHC SOURCE | SHCS, 6-32, .375LG, SST | 2 EA | E47000017 |
| 810/900 IHC SOURCE | CLAMP ARM, PH1 | 2 EA | E17302120 |
| 810/900 IHC SOURCE | CLAMP FILAMENT VER.2 IHC | 2 STK | E17292540 |
| 810/900 IHC SOURCE | FILAMENT, PH1, W | 1 STK | E17297920 |
| 810/900 IHC SOURCE | SHCS, 4-40, .460LG, MO | 1 EA | E17295210 |
| 810/900 IHC SOURCE | CATHODE CLAMP, VIISTA | 1 STK | E17331970 |
| 810/900 IHC SOURCE | CATHODE, STD, OP, HC | 1 STK | E17295630 |
| 810/900 IHC SOURCE | END CAP, IHC SOURCE | 1 STK | E17220310 |
| 810/900 IHC SOURCE | PLATE, SIDE, IHC ARC CHAMBER | 2 STK | E17220340 |
| 810/900 IHC SOURCE | SOURCE FRONT PLATE, VMC | 1 EA | E17220370 |
| 810/900 IHC SOURCE | PLATE, END, REP | 1 STK | E17304690 |
| 810/900 IHC SOURCE | REPELLER, 810, OP | 1 STK | E17285280 |
| 810/900 IHC SOURCE | REPELLER CLAMP, HC | 1 STK | E17292550 |
| 810/900 IHC SOURCE | MC CLAMP ARM, IHC | 2 EA | E17302110 |
| 810/900 IHC SOURCE | SST SHCS .625LG | 2 EA | E47000010 |
| 810/900 IHC SOURCE | STRAP, FILAMENT CLAMP, LEFT, IHC 80 | 1 EA | E17284470 |
| 810/900 IHC SOURCE | STRAP, FILAMENT CLAMP, RIGHT, IHC | 1 EA | E17284400 |
| 810/900 IHC SOURCE | STRAP CATHODE VER.2 IHC | 1 STK | E17316430 |
| 810/900 IHC SOURCE | INSULATOR, DUAL MOUNT, HC | 4 EA | E17296280 |
| 810/900 IHC SOURCE | NUTPLATE, BARCLAMP, HC/MC | 2 STK | E17292510 |
| 810/900 IHC SOURCE | NUT, 4-40, MO | 1 EA | E17291350 |
| 810/900 IHC SOURCE | PLATE, BASE, IHC ARC CHAMBER | 1 STK | E17288230 |
| 810/900 IHC SOURCE | GRAPHITE INSERT | 1 EA | E17121520 |
| 810/900 IHC SOURCE | GAS TUBE, IHC, SOURCE | 1 EA | E17286660 |
| 810/900 IHC SOURCE | CLAMP POST, CATHODE STRAP, IHC | 1 EA | E17296360 |
| 810/900 IHC SOURCE | INSULATOR, BASE FEEDTHRU | 1 EA | E17296000 |
| 810/900 IHC SOURCE | BASE PLATE, A/C, PH2, NV, ASSY | 1 AS |
|
| 810/900 IHC SOURCE | REPELLER, IHC TEXTURE | 1 STK |
|
| 810/900 CLAMP OPTIONS | FILAMENT CLAMP IHC SOURCE LEFT | 1 STK | E17288210 |
| 810/900 CLAMP OPTIONS | FILAMENT CLAMP IHC SOURCE RIGHT | 1 STK | E17288200 |
| 810/900 CLAMP OPTIONS | CLAMP CATHODE IHC 810 ASSY | 1 STK | E17288190 |
| 810/900 CLAMP OPTIONS | SHCS, 4-40, .460LG, MO | 2 EA | E17295210 |
| 810/900 CLAMP OPTIONS | NUT, 4-40, MO | 2 EA | E17291350 |
| 810/900 CLAMP OPTIONS | CLAMP ARM, PH2/3 | 2 STK |
|
| 810/900 CLAMP OPTIONS | FILAMENT CLAMP, PH 2/3 | 2 EA |
|
| 810/900 CLAMP OPTIONS | NUTPLATE, BARCLAMP, HC/MC | 4 STK | E17292510 |
| 810/900 CLAMP OPTIONS | SHCS, 6-32, .375LG, SST | 2 EA | E47000017 |
| 810/900 CLAMP OPTIONS | MC CLAMP ARM, IHC | 2 EA | E17302110 |
| 810/900 CLAMP OPTIONS | CATHODE CLAMP, VIISTA | 1 STK | E17331970 |
| 810/900 CLAMP OPTIONS | SST SHCS .625LG | 1 EA | E47000010 |
| 810/900 CLAMP OPTIONS | SHCS, 4-40, .460LG, MO | 1 EA | E17295210 |
| 810/900 CLAMP OPTIONS | NUT, 4-40, MO | 2 EA | E17291350 |
| 810/900 CLAMP OPTIONS | CLAMP, REPELLER, VIISTA | 1 EA |
|
| 810/900 CLAMP OPTIONS | CLAMP FILAMENT VER.2 IHC | 2 STK | E17292540 |
| 810/900 CLAMP OPTIONS | CLAMP CATHODE IHC810 ASSY | 1 STK |
|
| 810 EXTRACTION | GROUND ELECTRODE, 810 | 1 EA | E17167300 |
| 810 EXTRACTION | W ELECTRODE SUPPRESSION | 1 STK | E17273910 |
| 810 EXTRACTION | BLOCK, EXTRACTION ELEC SPACER | 1 EA | E17273920 |
| 810 EXTRACTION | INSULATOR, 60 KV | 3 EA | E17091851 |
| 810 EXTRACTION | ELECTRODE, SUPPRESSION FRAME | 1 STK |
|
| 810 EXTRACTION | GROUND ELECTRODE FRAME | 1 EA |
|
| 810 EXTRACTION | GRAPHITE SCREW | 4 EA |
|
| 810 EXTRACTION | INSERT, ELECTRODE, VMC, GPH | 2 EA |
|
| 810 EXTRACTION | INSERT, ELECTRODE, VMC, W | 2 EA |
|
| 810XE/XER EXTRACTION | BLOCK, SPACER, GRAPHITE | 1 EA | E17314370 |
| 810XE/XER EXTRACTION | PLATE, SUPPRESSION | 1 EA | E17280860 |
| 810XE/XER EXTRACTION | SUPPRESSION ELECTRODE | 1 STK | E17280880 |
| 810XE/XER EXTRACTION | INSULATOR, SUPPRESSION ASSY | 3 EA | E17280850 |
| 810XE/XER EXTRACTION | GROUND ELECTRODE, 810 | 1 STK | E17280890 |
| 810XE/XER EXTRACTION | INSERT, ELECTRODE, VMC, GPH | 2 EA |
|
| 810XE/XER EXTRACTION | INSERT, ELECTRODE, VMC, W | 2 EA |
|
| 810XE/XER EXTRACTION | FRAME, SUPP ELECTRODE, XER, XPT | 1 EA |
|
| 810XE/XER EXTRACTION | GROUND ELECTRODE, FRAME | 1 EA |
|
| 810XE/XER EXTRACTION | GRAPHITE SCREW | 4 EA |
|
| SUPPRESSION ASSY, VMC | COVER, GRAPHITE | 1 STK | G17597450 |
| SUPPRESSION ASSY, VMC | PLATE, SUPPRESSION | 1 STK | G17597480 |
| SUPPRESSION ASSY, VMC | SHIELD, GROUND, SUPPRESSION ASSY | 3 STK | G17597500 |
| SUPPRESSION ASSY, VMC | BLOCK, SPACER, GRAPHITE | 1 STK | G17597540 |
| SUPPRESSION ASSY, VMC | INSULATOR, SUPPRESSION/ GROUND | 3 STK | E17406960 |
| SUPPRESSION ASSY, VMC | ELECTRODE, SUPPRESSION FRAME | 1 STK | E17745020 |
| SUPPRESSION ASSY, VMC | INSERT ELECTRODE SUPPRESSION | 1 STK | G17597470 |
| SUPPRESSION ASSY, VMC | SCREW, 4-40 X .1 | 1 STK | E17707850 |
| SUPPRESSION ASSY, VMC | GROUND ELECTRODE, 810 | 2 STK | E17708400 |
| SUPPRESSION ASSY, VMC | Y_PLATE, GROUND, SUPPRESSION | 1 STK | E17280890 |
| SUPPRESSION ASSY, VMC | INSERT ELECTRODE SUPPRESSION | 1 STK | G17597490 |
| SUPPRESSION ASSY, VMC | CUP, TRANSFER PLATE | 3 STK | G17597510 |
| 900/900XPT/HE EXTRACTION | SPACE BLOCK, 900XPT EXT | 3 STK | E17790410 |
| 900/900XPT/HE EXTRACTION | ELECTRODE, SUPPRESSION FRAME | 1 STK | E17745020 |
| 900/900XPT/HE EXTRACTION | INSERT ELECTRODE SUPPRESSION | 1 STK | E17707850 |
| 900/900XPT/HE EXTRACTION | SCREW, 4-40 X .1 | 2 STK | E17708400 |
| 900/900XPT/HE EXTRACTION | INSULATOR, SUPPRESSION/ GROUND | 3 STK | E17406960 |
| 900/900XPT/HE EXTRACTION | GROUND ELECTRODE, 810 | 1 STK | E17280890 |
| 900/900XPT/HE EXTRACTION | ELECTRODE, SUPPRESSION HE | 1 STK | E17755880 |
| 900/900XPT/HE EXTRACTION | ELECTRODE GROUND, GPH, 810 | 1 STK | E17513530 |
| 810 RESOLVING APERTURE | INSULATOR | 2 EA | E17159960 |
| 810 RESOLVING APERTURE | INSULATOR | 2 EA | E17159920 |
| 810 RESOLVING APERTURE | FARADAY SHIELD | 1 EA | E17239750 |
| 810 RESOLVING APERTURE | SHIELD, APERTURE, EXIT | 1 EA | E17239760 |
| 810 RESOLVING APERTURE | HOUSING LINER | 1 EA | E17234890 |
| 810 RESOLVING APERTURE | RESOLVING APERTURE SHIELD | 1 EA | E17160860 |
| 810 RESOLVING APERTURE | SHIELD AND EXIT, RESOLVING | 1 EA |
|
| 810 ELECT UPSTREAM ACCEL COLUMN | ACCEL COLUMN, FRAME | 1 EA |
|
| 810 ELECT UPSTREAM ACCEL COLUMN | ACCEL COLUMN, INSERT | 1 EA |
|
| 810 ELECT UPSTREAM ACCEL COLUMN | SCREW, FH, GPH, 632, .22LG | 2 EA |
|
| 810 ANALYZER 90° | APERTURE, ENTRANCE, ANALYZER | 1 STK | E17307550 |
| 810 ANALYZER 90° | LINER, BOTTOM POLE | 1 EA | E17151480 |
| 810 ANALYZER 90° | LINER, TOP POLE | 1 EA | E17151490 |
| 810 ANALYZER 90° | APERTURE ENTRANCE | 1 EA | E17195970 |
| 810 ANALYZER 90° | LINER, ANALYZER MAG, TOP POLE | 1 STK | E17303740 |
| 810 ANALYZER 90° | LINER, ANALYZER MAGNET, BOTTOM | 1 STK | E17303730 |
| 810 PLASMA FLOOD | PFG APERTURE* | 1 EA | E17225960 |
| 810 PLASMA FLOOD | PFG FILAMENT, .050 | 1 EA | E17041850 |
| 810 PLASMA FLOOD | PFG FILAMENT CLAMP ASSY, TA | 2 EA | E17324960 |
| 810 PLASMA FLOOD | PFG FILAMENT INSULATOR | 1 EA | E17270580 |
| 810 PLASMA FLOOD | NUT, FILAMENT CLAMP | 2 EA | E17058140 |
| 810 PLASMA FLOOD | RETAINER, PFG FILAMENT | 2 EA | E17116730 |
| 810 PLASMA FLOOD | APERTURE,PFG,IMPREG,IMP | 1 EA | E17225961 |
| 810 PLASMA FLOOD | PFG FILAMENT | 1 STK | E17041850 |
| 810 PLASMA FLOOD | CLAMP, FILAMENT | 2 STK | E17042050 |
| 810 PLASMA FLOOD | HOLDER, CLAMP | 2 STK | E17042040 |
| 810 PLASMA FLOOD | FILAMENT INSULATOR, PFG | 1 EA | E17042000 |
| 810 PLASMA FLOOD | NUT, FILAMENT CLAMP | 2 EA | E17058140 |
| 810 PLASMA FLOOD | RETAINER, PFG FILAMENT | 2 EA | E17116730 |
| 810 PLASMA FLOOD | FILAMENT BERNAS PFG | 1 STK | G17696400 |
| 810 PLASMA FLOOD | PIG TAIL FILAMENT PFG JIG | 1 STK |
|
| 810 PLASMA FLOOD | FILAMENT, PFG | 1 STK | E17041851 |
