产品介绍
The Keysight DSOX4032G Digital Oscilloscope is a mid-range InfiniiVision 4000G X-Series that combines high frequency, measurement accuracy, and convenient touch control.
Equipped with two analog channels with a bandwidth of 350 MHz and a sample rate of up to 5 GS/s, it provides reliable analysis of both analog and digital signals in complex systems.
MegaZoom IV ASIC technology guarantees refresh rates of up to 1,000,000 waveforms/s, and the 12.1" touchscreen with gesture support provides intuitive operation.
Mask / Limit Test, FRA (Bode Plot), built-in 20 MHz WaveGen oscillator, DVM, frequency counter, as well as a D4000GENB package for hardware decoding of I²C, SPI, UART, CAN, LIN and USB PD protocols are installed as standard.
Features
2 analog channels, 350 MHz bandwidth
Sample rate up to 5 GS/s (1/2 channels)
Memory depth 4 Mtps / 2 Mtps (all channels)
Update rate up to 1,000,000 forms/s
Built-in 20 MHz WaveGen (Features & AWG)
FRA (Bode Plot), mask and limit tests
12.1" touchscreen with gesture support
DVM and frequency counter as standard
Hardware decoding of I²C, SPI, UART, CAN, LIN, USB PD protocols
Compatible with Probe AutoProbe, BenchVue, and Infiniium Offline
