The Keysight DSOX4022G InfiniiVision 4000G X-Series digital oscilloscope combines professional performance, touch control, and high waveform refresh rates of up to 1,000,000 waveforms/s.
With a 12.1" touchscreen display, MegaZoom IV smart memory technology, and a built-in 20MHz dual-channel WaveGen signal generator, the model provides the highest accuracy and convenience for signal analysis.
The DSOX4022G model combines seven devices in one housing:
Oscilloscope
Serial Protocol Analyzer
Dual-Channel Signal Generator (AWG)
3-digit voltmeter (DVM)
Frequency Response Analyzer (Bode Plot)
8-bit frequency counter
Mask and Limit Testing Tools
The oscilloscope is designed for a wide range of applications, from debugging digital and analog circuits to measurements in power electronics, automotive systems, and educational labs.
Features
200 MHz bandwidth (extensible under license)
Maximum sample rate of 5 GS/s (interliving)
Memory depth 4 Mtps (2 Mtps on all channels)
Waveform update rate up to 1,000,000 forms/s
Built-in dual-channel 20 MHz WaveGen signal generator
12.1" TFT Touch Display with Gesture Control
Support for 36 automatic measurements and advanced math
Zonal trigger and segmented memory (up to 1000 segments)
Hardware decoding of I²C, SPI, UART, CAN, LIN, USB PD protocols
FRA (Frequency Response Analysis) - Standard on G-Models
DVM + frequency counter as standard
Compatible with BenchVue, Infiniium Offline oscillographic software
